ALFA-B 22518MP

ALFA-B 22518MP

by | 2024 Mar 13 | ALFA trailers, ALFA universal platform trailers, ALFA-B universal flatbed front-wheel single-axle trailers with wheelchair

Productions

Braked, one-axle, universal flatbed trailer.
Universal passenger car trailer flatbed, which can be used as a motorcycle and cargo trailer thanks to the rich accessories.

Type ALFA-B 22518MP
Total weight (kg) 1300-1500
Own weight (kg) 280 – 310
Load capacity (kg) function of total weight
Total weight (kg) 750-800-850-900-950-1000-1050-1100-1150-1200-1250-1300-1350-1400-1450-1500
Wheel 165R13C,185R14C
Internal dimensions (mm) 2560×1800(300)
Total size (mm): 3720x2150x670
Axle torsion

Information

  • strong, galvanized chassis with V-shaped tow bar
  • approved design switch head
  • floor made of non-slip laminated wood
  • KNOTT chassis with torsion spring
  • Jokon lamp
  • 4 mounting hooks
  • 12 V electrical system
  • 7-pin adapter
  • 13” wheel

Options

  • LED1 lamp
  • Quick support
ALFA-B 23015MN

ALFA-B 23015MN

by | 2024 Mar 11 | ALFA trailers, ALFA-B open front wheeled single axle trailers with wheelchair, ALFA-B single-axle trailers with brakes, Trailers with brakes

Productions

Front-wheel (MN), open, single-axle braked trailer with fixed sidewall.
Downgrading is possible when ordering in 50kg increments up to 750kg.

Type ALFA-B 23015MN
Total weight (kg) 1000-1500
Own weight (kg) 330
Load capacity (kg) 695-1170
Total weight (kg) 750-800-850-900-1000-1100-1200-1300-1400-1500
Wheel 13″
Internal dimensions (mm) 2940x1440x355
Total size (mm): 4080x1850x870
Axle torsion or leaf spring

INFORMÁCIÓ

  • Information
  • side walls made of galvanized sheet
  • openable rear door with safety lock
  • galvanized V-shaped chassis
  • approved design switch head
  • floor made of non-slip laminated wood
  • overrun brake with automatic reversing
  • KNOTT chassis with torsion spring
  • Jokon lamp
  • 4 mounting hooks
  • hooking buttons for attaching a tarpaulin
  • 12 V electrical system
  • 13-pin adapter
  • 13” wheel

Options

  • LED1 lamp
  • MT wheel clamp stand for 15-21″ wheel
ALFA-B 23015MN.130 Alu

ALFA-B 23015MN.130 Alu

by | 2024 Mar 11 | ALFA aluminium sidewall trailers, ALFA trailers

Productions

Aluminium side wall open trailer without brakes, front wheel (MN), open, single axle with fixed side wall.
MN – open front trailer
Confirmation possible on order in 50kg increments up to 300kg

Type ALFA-B 23015MN.130 Alu
Total weight (kg) 1300
Own weight (kg) 310
Load capacity (kg) 990
Total weight (kg) 750-800-850-900-950-1000-1050-1100-1150-1200-1250-1300
Wheel 13″
Internal dimensions (mm) 2950x1450x350
Total size (mm): 4080x1850x900
Axle torsion

Information

  • side walls in 350mm double-walled aluminium profile

  • opening rear door with safety lock

  • galvanised V-shaped chassis

  • approved switch head construction

  • non-slip plywood floor

  • KNOTT torsion or leaf-spring suspension

  • Jokon analogue lamp

  • 4 fixing clamps

  • for attaching hooks to tarpaulins

  • 12 V electric system

  • 13-pin adapter

  • 13″ wheel

Options

  • LED1 light

ALFA-B 23016AP

ALFA-B 23016AP

by | 2024 Mar 13 | ALFA trailers, ALFA-B single-axle trailers with brakes, ALFA-B universal flatbed lower wheel single axle trailers with wheelchair, Trailers with brakes

Productions

Braked, single axle front wheel (AP) universal flatbed trailer.

Below a total weight of 900kg, the desired total weight can change in 50kg increments, above 900kg in 100kg increments.

It can be ordered in a total weight of 750 – 1500 kg.

Type ALFA-B 23016AP
Total weight (kg) 1300-1500-1800
Own weight (kg) 290-305-315
Load capacity (kg) function of total weight
Total weight (kg) 750-800-850-900-1000-1100-1200-1300-1400-1500-1600-1700-1800
Wheel 195/55R10C és 195/50R13C
Internal dimensions (mm) 3045×1600(300)
Total size (mm): 4170x1600x596
Axle torsion

Information

  • universal low-wheel passenger car trailer platform, which can be used as a motorcycle and cargo trailer thanks to the rich accessories
  • strong, galvanized chassis with V-shaped drawbar
  • switch head with authorized structure
  • floor made of non-slip laminated wood
  • KNOTT chassis with torsion springs
  • switch head with authorized structure
  • Jokon lamp
  • 8 mounting hooks
  • 12 V electrical system
  • 13-pin adapter
  • 13” wheel

*These are flatbed trailers, side walls must be ordered separately!*

Options

  • LED1 lamp
  • Aluminum side false set, all sides can be opened
ALFA-B 22518MP

ALFA-B 23016MP

by | 2024 Mar 13 | ALFA trailers, ALFA-B single-axle trailers with brakes, ALFA-B universal flatbed front-wheel single-axle trailers with wheelchair, Trailers with brakes

Productions

Braked, single axle front wheel (MP) universal flatbed trailer.

Below a total weight of 900kg, the desired total weight can change in 50kg increments, above 900kg in 100kg increments.

It can be ordered in a total weight of 750, 1000, 1300, 1500 kg.

Type ALFA-B 23016MP
Total weight (kg) 750-1000-1300-1500-1800
Own weight (kg) 235-285-290-310
Load capacity (kg) function of total weight
Total weight (kg) 750-800-850-900-950-1000-1050-1100-1150-1200-1250-1300-1350-1400-1450-1500-1550-1600-1650-1700-1750-1800
Wheel 13″-14″
Internal dimensions (mm) 3045×1600(300)
Total size (mm): 4170x1950x670
Axle torsion

Information

  • universal front-wheel passenger car trailer platform, which, thanks to the rich accessories, can also be used as a motorcycle and cargo trailer

  • strong, galvanized chassis with V-shaped tow bar

  • approved design switch head

  • floor made of non-slip laminated wood

  • KNOTT chassis with torsion spring

  • approved design switch head

  • Jokon lamp

  • 4 mounting hooks

  • 12 V electrical system

  • 13-pin adapter

  • 13” wheel

*These are flatbed trailers, side walls must be ordered separately!*

Options

  • LED1 lamp
  • MT wheel clamp stand for 15-21″ wheel
