ALFA-T 43015MVG trailers

ALFA-T 43015MVG trailers

by | 2024 May 9 | ALFA trailers, ALFA transport trailers

PRODUCTIONS

Bi-axle lower wheeled machine trailer. Total weight can be reduced per 100 kg.
3000 kg load capacity drive-on ramp.

Type ALFA-T 43015MVG.270 ALFA-T 43015MVG.300 ALFA-T 43015MVG.350
Total weight (kg) 2700 3000 3500
Own weight (kg) 570 630 660
Load capacity (kg) function of total weight
Total weight (kg) 900-1000-1100-1200-1300-1400-1500-1600-1700-1800-1900-2000-2100-2200-2300-2400-2500-2600-2700-2800-2900-3000-3100-3200-3300-3400-3500
Wheel 195/50R13
Internal dimensions (mm) 3000x1500x340
Total size (mm): 4820x2100x1670
Axle torsion

INFORMATION

  • Lower wheeled machine trailer with 2700-3500 kg load capacity drive-on ramp

  • strong, galvanised chassis with V-shaped drawbar

  • approved coupling head design

  • floor made of non-slip plywood

  • KNOTT torsion spring suspension

  • approved coupling head structure

  • analog lamp

  • 8 fixing clamps

  • 12 V electrical system

  • 13-pole adapter

  • 13″ wheel

Options

  • LED1 lamp

ALFA-T 43016AP

ALFA-T 43016AP

by | 2024 Mar 13 | ALFA trailers, ALFA-T two-axle trailer with brake, ALFA-T universal flatbed lower wheel two axle trailers with wheelchair, Trailers with brakes

Productions

Braked, two-axle underwheel (AP) universal flatbed trailer.

Universal passenger car trailer flatbed, which can be used as a motorcycle and cargo trailer thanks to the rich accessories.

Below a total weight of 900kg, the desired total weight can change in 50kg increments, above 900kg in 100kg increments.

It can be ordered in a total weight of 900 – 2700 kg.

Attention! The side set, lattice superstructure reduces the size of the platform by approx. 60mm!

Type ALFA-T 43016AP
Total weight (kg) 1300-2000-2500
Own weight (kg) 370-375-390
Load capacity (kg) function of total weight
Total weight (kg) 900-1000-1100-1200-1300-1400-1500-1600-1700-1800-1900-2000-2100-2200-2300-2400-2500-2600-2700
Wheel 10″
Internal dimensions (mm) 3045×1600(300)
Total size (mm): 4270x1600x595
Axle torsion

Information

  • universal tandem-axle, lower-wheel passenger car trailer platform, which, thanks to the rich accessories, can also be used as a motorcycle and cargo trailer
  • strong, galvanized chassis with V-shaped drawbar
  • switch head with authorized structure
  • floor made of non-slip laminated wood
  • KNOTT chassis with torsion springs
  • switch head with authorized structure
  • Jokon lamp
  • 8 mounting hooks
  • 12 V electrical system
  • 13-pin adapter
  • 10” wheel

*These are flatbed trailers, side walls must be ordered separately!*

Options

  • LED1 lamp
  • Aluminum side false set, all sides can be opened
ALFA-T 43016MP

ALFA-T 43016MP

by | 2024 Mar 13 | ALFA trailers, ALFA-T two-axle trailer with brake, ALFA-T universal flatbed front-wheel drive two single-axle trailers with wheelchair, Trailers with brakes

Productions

Braked, front-wheel (MP), two-axle universal flatbed trailer.

Universal passenger car trailer flatbed, which can be used as a motorcycle and cargo trailer thanks to the rich accessories.

Below a total weight of 900kg, the desired total weight can change in 50kg increments, above 900kg in 100kg increments.

It can be ordered in a total weight of 900 – 3000 kg.
Attention! The side set, lattice superstructure reduces the size of the platform by approx. 60mm!

Type ALFA-T 43016MP
Total weight (kg) 1300-2000-2500-2700
Own weight (kg) 370-375-390
Load capacity (kg) function of total weight
Total weight (kg) 900-1000-1100-1200-1300-1400-1500-1600-1700-1800-1900-2000-2100-2200-2300-2400-2500-2600-2700
Wheel 13″
Internal dimensions (mm) 3045×1600
Total size (mm): 4170x1950x670
Axle torsion

Information

  • universal tandem-axle, front-wheel passenger car trailer platform, which, thanks to the rich accessories, can also be used as a motorcycle and cargo trailer
  • strong, galvanized chassis with V-shaped drawbar
  • switch head with authorized structure
  • floor made of non-slip laminated wood
  • KNOTT chassis with torsion springs
  • switch head with authorized structure
  • Jokon lamp
  • 8 mounting hooks
  • 12 V electrical system
  • 13-pin adapter
  • 13” wheel

*These are flatbed trailers, side walls must be ordered separately!*

Options

  • LED1 lamp
  • MT wheel clamp stand for 15-21″ wheel
ALFA-T 43018AP

ALFA-T 43018AP

by | 2024 Mar 13 | ALFA trailers, ALFA universal platform trailers, ALFA-T universal flatbed lower wheel two axle trailers with wheelchair

Productions

Universal platform with lower wheels and two axles with brakes.
AP – front wheel platform
The trailer is made with a total weight of 900-2700 kg, increasing in 100 kg increments.
When requesting a quote / ordering, please specify the desired total weight of the trailer!
Attention! The side set, lattice superstructure reduces approx. 60mm the size of the platform!

Type ALFA-T 43018AP
Total weight (kg) 1300-2000-2700-3500
Own weight (kg) 425-440-445
Load capacity (kg) function of total weight
Total weight (kg) 900-1000-1100-1200-1300-1400-1500-1600-1700-1800-1900-2000-2100-2200-2300-2400-2500-2600-2700
Wheel 10″
Internal dimensions (mm) 3045×1800(300)
Total size (mm): 4270x1800x595
Axle torsion

Information

  • universal tandem-axle, lower-wheel passenger car trailer platform, which, thanks to the rich accessories, can also be used as a motorcycle and cargo trailer
  • strong, galvanized chassis with V-shaped tow bar
  • switch head with authorized structure
  • floor made of non-slip laminated wood
  • KNOTT chassis with torsion springs
  • switch head with authorized structure
  • Jokon lamp
  • 8 mounting hooks
  • 12 V electrical system
  • 13-pin adapter
  • 10” wheel

Options

  • LED1 lamp
  • Side wall set, all sides open
ALFA-T 43018MP

ALFA-T 43018MP

by | 2024 Mar 13 | ALFA motorcycle transport trailers, ALFA trailers, ALFA universal platform trailers, ALFA-T universal flatbed front-wheel drive two single-axle trailers with wheelchair

Productions

Braked universal flatbed trailer.
Universal trailer platform for passenger cars, which can also be used as a motorcycle and cargo trailer thanks to the rich accessories.

Type ALFA-T 43018MP
Total weight (kg) 1300-2000-2700
Own weight (kg) 430-445-450
Load capacity (kg) function of total weight
Total weight (kg) 900-1000-1100-1200-1300-1400-1500-1600-1700-1800-1900-2000-2100-2200-2300-2400-2500-2600-2700
Wheel 13″
Internal dimensions (mm) 3045×1800(300)
Total size (mm): 4170x2150x670
Axle torsion

Information

  • strong, galvanized chassis with V-shaped drawbar
  • switch head with authorized structure
  • floor made of non-slip laminated wood
  • KNOTT chassis with torsion springs
  • Jokon lamp
  • 4 mounting hooks
  • 12 V electrical system
  • 7-pin adapter
  • 13” wheel

Options

  • LED1 lamp
